Swampfox Optics Arrowhead Scope, 1-10x24mm, Black, LPVO Series

The Swampfox Arrowhead is their flagship LPVO (low power variable optic) series that exceeds all requirements for end-user applications. Every Arrowhead comes with push/pull locking turrets to ensure accuracy and prevent unintentional adjustments. Arrowhead also features a brighter sight picture, expansive field of view, and excellent resolution. Offered in three second focal plane reticles: Guerrilla Dot BDC Long, Guerrilla Dot MOA Long, and Guerrilla Dot MIL, each with 12 red or green illumination settings. The Arrowhead is an excellent choice for both close quarters and long-distance engagements.

---

• Magnification : 1-10x
• Tube Diameter : 30mm
• Objective Lens Diameter : 24mm
• Exit Pupil (mm) : 8.0mm-2.3mm (1x-10x)
• Eye Relief (in) : 3.46-3.54" (1x-10x)
• FOV @ 100 Yards (ft) : 115.6-11.5' (1x-10x)
• Click Value : 1/2 MOA or 0.1 MIL (reticle dependent)
• Parallax Setting : 100 yds
• Travel Per Rotation : 60 Clicks/ 30 MOA
• Max Elevation Adjustment : 100 MOA
• Max Windage Adjustment : 100 MOA
• Lens Coating : Fully Multi-Coated/ Anti-fog/ Hydrophobic
• Illumination : 12 Position Illumination Turret
• Battery : Side-mounted CR2032 Battery
• Reticle : BDC or MOA Glass Etched Illuminated
• Magnification Required for Reticle Accuracy : 10x
• Fast Focus Diopter : Yes, -2 to +2
• Turret Style : Push/Pull Locking Turrets with Zero Reset
• Length : 10.91"
• Weight : 20.36 oz
• Waterproof Rating : IPX7
• Impact Resistance : 1,100 G Forces
